* Independent Research and Development Product, Core Technology and Exclusive Design by AGR

Large Agriculture Drone is equipped with plant protection flight control and agricultural intelligent data processing platform, as well as four pump accurate metering spray system, combined with FPV, obstacle avoidance and other auxiliary operating systems, can achieve accurate plant protection operations, making plant protection operations simple and safe. Based on the second-generation flight control technology architecture, the new AG3 series flight control system is safe and reliable, optimized for the plant protection industry, improves work efficiency, and realizes intelligent operation of drone plant protection.

The modular structure design of the Large Agriculture Drone machine body makes the fragile parts such as the arm, motor, electric adjustment and so on disassemble and replace quickly if there are faults or damages, which makes the later maintenance more convenient and economical.

Model	A16 2020
Motor Type	Brushless Motor X 4
Hourly Operating Area	4-10 Hectare
Operation Area per Tank	1 Hectare (16L/Hectare)
Droplet Size	80-250 μm
Flow Rate	1L/min - 8L/min
Spray Width	3-6m
Battery Type	Lithium-ion
Maximum Attitude	30m
Cover Finshing	Light Blue /Blue/Red/Grey/White/Customized
Full Loading Weight	36.43KG
Product Size	1200mm×1191mm×555mm
Packing Size	1025mm×755mm×565mm
Aircraft Weight	14.23kg

1. Accurate spraying to avoid heavy leakage

The new spraying system: four pump independent control system, according to the flight speed, work together to further expand the flow interval to ensure uniformity of spraying; with high-precision flowmeter, it can achieve accurate mu dosage, statistical error ≤ 5%.

2, the perception of obstacles

During flight, the plant protection Large Agriculture Drone machine can sense the obstacle's azimuth and distance through the real-time scanning of obstacle avoidance in the front and rear direction; when the obstacle enters the warning area, the aircraft will automatically stop and record the interruption coordinate point. By controlling the plant protection machine to bypass the obstacles in the front, rear, left and right directions by the lever, it can automatically return to the planned projection point of the route and continue the operation.

3, intelligent scanning, accurate imitation

The distance between the plant protection machine and the vegetation to be applied is sensed in real time, and the control system is continuously adjusted to ensure that the distance between the plant protection Large Agriculture Drone machine and the vegetation remains unchanged, and the uniformity of spraying is ensured. Depending on the actual application environment, the sensitivity can be adjusted to suit most crops and topography.

4, multiple modes free switching

Users can set flight and operation parameters according to actual operation requirements. The plant protection Large Agriculture Drone machine can automatically complete route planning and provide users with four operation modes: AB point operation, area planning operation, semi-automatic operation or manual operation to meet different environmental operation requirements.

5, safe and reliable, reliable operation

Electronic control system upgrade, dual backup configuration, industrial grade calibration, built-in shock absorption structure to improve the safety of plant protection operations. The plant protection platform made of high-strength carbon fiber has a lightweight and sturdy body structure. Enclosed folding design saves space and facilitates transition.

6, intelligent management, convenient and efficient

Automatically plan flight routes, take off at the touch of a button, return to land with one button, voice broadcast, and intelligent assistants to enhance the control experience.

Intelligent spray setting, accurate calculation of work area, automatic generation of job reports, accurate spraying of high-efficiency medication. Aircraft management, operations team management, task management, and teamwork improve operational efficiency.

7, centimeter-level positioning, accurate orientation

The plant protection Large Agriculture Drone drone is equipped with an RTK system for high-precision flight and centimeter-accurate positioning. At the same time, Large Agriculture Drone is equipped with dual antenna configuration for accurate flight control, without fear of magnetic compass interference.
