70L fertilizer tank with a Upper and lower segmented shaftdesign Greater motor torque.
arge charging hole. of spreader eases washingand maintenance Higher discharge rate
can easily load a package Screws of whole fuselage are exter. nal and and widerSeeding
of fertilizer. Large filter quick-detachable, achieving easy cleaning amplitude.
break up the caking easily and maintenance infield operations.
Whole Parameter
|
Rated Load
|
40kg
|
Max Load
|
45kg
|
|
No-load Weight
|
48.4kg
|
Rated Takeoff Weight
|
88.4kg
|
|
Transport Dimension
|
1100mm*900mm*980mm
|
Overall Dimension
|
1540mm*1520mm*930mm
|
|
No-load Hovering Time
|
18min15s
|
Full-load Hovering Time
|
7min30s
|
Spreading Parameter
|
Fertilizer Tank Volume
|
70L
|
Spreading Efficiency
|
5.3 Ha/h
|
|
Spreading Endurance
|
Each battery 6 times, 240kg fertilizer
|
Max Discharging Rate
|
80kg/min
|
|
Spreading Range
|
6~15m(varies with the discharging rate of height)
|
Suitable Material
|
0.5~20mm dry solid particle
|
Spraying Parameter
|
Pesticide Tank Volume
|
40L
|
Spraying Efficiency
|
6.7~20 Ha/h
|
|
Spraying Range
|
5~7.5m( varies with height)
|
Flow Rate
|
8L/min
|
|
Number of Nozzles
|
16
|
Atomizing Diameter
|
80~250μm
|
|
Filtration Grade
|
Level 3(dosing hole, discharging hole,nozzle)
|
Battery Parameter
|
Model
|
ZAB1830
|
Weight
|
about 13.5kg
|
|
Battery Dimension
|
175mm*275mm*309mm
|
Cells
|
18S
|
|
Capacity
|
30000mAh
|
Nominal Voltage
|
68.4V
|
