Product Introduction
The A22 plant protection drone has three operating modes, and users can choose different operating modes for different plots and operating environments.
1. Manual operation mode
In the manual operation mode, the user starts and stops the spraying of pesticides through the remote control, adjusts the spraying flow at any time, etc., and controls the front, rear, left, right, and height of the drone through the remote control to spray the plot.
2. Intelligent operation mode
Intelligent operation mode, namely AB point mode, in this mode, the aircraft can spray pesticides along a specific route, control the drone to fly above the designated point through the remote control, and then set point A and point B, and the user can set the operation direction, operation distance, flight After the speed is reached, the APP will automatically generate the operation route, and the drone can enter the continuous intelligent operation state.
3. Route operation mode
In this mode, the user can use the remote controller to connect the GPS module to do the plot edge mapping and obstacle edge mapping, and automatically generate the route.


Model | A22 RTK |
Motor Type | Brushless Motor X 4 |
Hourly Operating Area | 4-14 Hectare |
Operation Area per Tank | Modularization Design, Fewer Accessories |
Droplet Size | 80-250 μm |
Flow Rate | 1L/Min - 8L/Min |
Spray Width | 3 - 8m |
Battery Type | Lithium-ion |
Maximum Attitude | 30m |
Cover Finshing | Light Blue /Blue/Red/Grey/White/Customized |
Full Loading Weight | 49.5kg |
Product Size | 1200mm×1191mm×570mm |
Packing Size | 1025mm×755mm×580mm |
Aircraft Weight | 19kg |
